TREKKING KNOW-HOW BUILT ON EXPERIENCE. Trust in our experience. The X-LIFE Bikes allow a relaxing ride so that you can enjoy nature. To enable maximum satisfaction, you only need to discover the right KTM trekking bike for your needs. For decades these bicycles have been at the forefront of people‘s minds when they think about trekking. All X-LIFE models are equipped with suspension fork and offer more grip than the on-road brothers. Integrated cable routing and a front reflector, incorporated into the fork bridge ensure the bikes are capable and attractive. The tapered headtube increases the steerer tube stiffness. The X-LIFE TRACK STREET and X-LIFE ACTION STREET models are already equipped with lights and mudguards. All other bikes can be upgraded when needed. Have fun on your next trip.

Specification

Specification

FRAME 28" Alloy 6061 OFFROAD T-2380-M
FORK Suntour SF20-NEX HLO DS 63
R. DERAILL. Shimano Acera M3000-SGS shadow
F. DERAILL. Shimano Altus M370
SHIFTLEV. Shimano Altus M2010
CRANKSET Shimano Acera T3010 / 48-36-26T
SPROCKET Shimano Altus HG201-9 / 11-34T
CHAIN Shimano Capreo HG53
BRAKE Shimano MT200
ROTOR Shimano Altus RT10 CL 160 / Altus RT10 CL 160
WHEEL F KTM Line - Shimano Tourney HB-TX505 CL 32H 100 QR / KTM 28" Casual 32H / Pillar 2.0 INOX silver
WHEEL R KTM Line - Shimano Tourney FH-TX505-8 CL 32H 135 QR / KTM 28" Casual 32H / Pillar 2.0 INOX silver
TIRE F
TIRE R SCHWALBE SMART K-Guard 47-622, black
GRIP KTM COMP ERGO Lock
BAR KTM LINE Riser 20 640mm
STEM KTM LINE 7°
HEADSET RITCHEY Zero Logic PRESS FIT 1-1/8"
SADDLE KTM LINE SPORT
SEATPOST KTM LINE 27.2
PEDAL KTM LINE Cross BF
WEIGHT 13,5 kg
PERMISSIBLE TOTAL WEIGHT 114 kg

Geometry

A Size 46
B Seattube length 460
C Toptube length 580
D Seat angle 73
E Head angle 70
F Headtube length 137
G Chainstay length 440
H Wheelbase 1070
I Stack 600
J Reach 397
K Standover height 797
L BB drop 55
A Size 51
B Seattube length 510
C Toptube length 590
D Seat angle 73
E Head angle 70
F Headtube length 155
G Chainstay length 440
H Wheelbase 1081
I Stack 617
J Reach 401
K Standover height 830
L BB drop 55
A Size 56
B Seattube length 560
C Toptube length 600
D Seat angle 73
E Head angle 70
F Headtube length 174
G Chainstay length 440
H Wheelbase 1092
I Stack 635
J Reach 406
K Standover height 861
L BB drop 55
A Size 60
B Seattube length 600
C Toptube length 615
D Seat angle 73
E Head angle 70
F Headtube length 190
G Chainstay length 440
H Wheelbase 1108
I Stack 650
J Reach 416
K Standover height 886
L BB drop 55
