GRAVEL UP YOUR LIFE. If you want to get the best out of every situation, then the KTM X STRADA range is the right choice for you. Gravel is not a trend, it is here to stay and makes for a very memorable ride. We have responded to the huge demand for our X STRADAs with all new developed frames. Moreover, we have doubled the number of models. In total, there are ten bikes to choose from. The PRIME, MASTER and ELITE versions use the X STRADA PRMIUM CARBON frame. This impresses with its clean and modern design. It’s constructed for a maximum tire width of 45mm. All three carbon models have a sporty design and bring a good portion of race feeling into the X STRADA family. The ROCK SHOX RUDY ULTIMATE fork with 40mm travel also makes its debut on the PRIME. Whether with or without suspension travel, your KTM Gravel experience will be more intense than ever before.

Specification

Specification

FRAME X-Strada Gravel Premium Carbon / R-2980
FORK RockShox Rudy Ultimate XPLR 40mm
R. DERAILL. SRAM Rival XPLR eTap AXS 12speed
F. DERAILL.
SHIFTLEV. SRAM Rival eTap AXS HRD
CRANKSET SRAM Rival 1 wide DUB 42T
SPROCKET SRAM Rival XPLR XG-1251 / 10-44
CHAIN SRAM Rival flattop 12s
BRAKE SRAM Rival hydraulic
ROTOR SRAM Paceline CL 160 / Paceline CL 160
WHEEL F DT Swiss GR 1600 SPLINE CL 100/12TA / 622x24TC
WHEEL R DT Swiss GR 1600 SPLINE CL 142/12TA / 622x24TC
TIRE F
TIRE R Continental Terra Speed TL 40-622 ProTection
GRIP KTM Tape
BAR KTM Team Road flare 16°
STEM KTM Team Road 8°
HEADSET Acros AICR internal 1.1/8>1.5" angle limit
SADDLE Selle San Marco Allroad Manganese Rails
SEATPOST KTM Team 27.2/350
WEIGHT 9,7 kg
PERMISSIBLE TOTAL WEIGHT 109 kg

Geometry

A Size 49
B Seattube length 490
C Toptube length 545
D Seat angle 73
E Head angle 68
F Headtube length 125
G Chainstay length 430
H Wheelbase 1055
I Stack 555
J Reach 384
K Standover height 776
L BB drop 58
A Size 52
B Seattube length 520
C Toptube length 565
D Seat angle 73
E Head angle 69
F Headtube length 140
G Chainstay length 430
H Wheelbase 1060
I Stack 573
J Reach 394
K Standover height 799
L BB drop 58
A Size 55
B Seattube length 550
C Toptube length 586
D Seat angle 72
E Head angle 70
F Headtube length 160
G Chainstay length 430
H Wheelbase 1066
I Stack 596
J Reach 401
K Standover height 824
L BB drop 58
A Size 57
B Seattube length 570
C Toptube length 606
D Seat angle 72
E Head angle 70
F Headtube length 170
G Chainstay length 430
H Wheelbase 1082
I Stack 604
J Reach 414
K Standover height 838
L BB drop 56
A Size 59
B Seattube length 590
C Toptube length 626
D Seat angle 71
E Head angle 70
F Headtube length 185
G Chainstay length 430
H Wheelbase 1098
I Stack 616
J Reach 424
K Standover height 855
L BB drop 55
