MACINA STYLE FS ELITE
1X11 SHIMANO DEORE LG
4.699 €
SRP
TREKKING, STYLE, SHOCK – IT´S A MATCH! Yes, the perfection of the MACINA STYLE concept can indeed be surpassed. For the new model year, the STYLE FS Prime arrives as a full suspension version with an additional 100mm of rear travel. In terms of comfort and versatility, this concept elevates the already popular trekking bike into a completely different league. The Performance Line CX (BDU384Y) takes riding dynamics and agility to a whole new level. It is powerful, light and quiet (100 Nm max. torque, 750-Watt max. motor power, 400% max. support factor). The Power Tube battery provides 800 Wh. POWER TUBE TOP LOADER (PTTL) is KTM’s innovation for user-friendly battery handling. Removing and reinserting the battery becomes a breeze.
Specification
Specification
| FRAME | Macina FS PERFORMANCE CARBON VPP100|PT800 Bosch BDU38/T5880 |
|---|---|
| FORK | Suntour NCX32-D SPORT Air 27" 2CR 100mm 15x110 |
| SHOCK | Suntour EDGE-X R 190x45 |
| MOTOR | Bosch PERFORMANCE CX BDU3840 (BOSCH PT-CX8K2) |
| DISPLAY | Bosch KIOX 500 TFT Display |
| BATTERY | Bosch PowerTUBE 800Wh horizontal - ABUS integrated lock IT1 (X-Plus key) |
| CHARGER | Bosch COMPACT Charger 2A |
| R.DERAILL | Shimano DEORE M7230-11 LG ShadowES |
| SHIFTLEV. | Shimano CUES U6000-11 LG /Display |
| CRANKSET | KTM E-COMP2 ISIS 170mm Q8 |
| CHAIN | Shimano LG500-9/10/11 |
| TIRE F | Schwalbe Green Marathon Perf. GreenGuard 55-584 |
| TIRE R | Schwalbe Green Marathon Perf. GreenGuard 55-584 |
| GRIPS | GRIP ERGON GP10 |
|---|---|
| BAR | KTM TEAM II rizer15 700mm |
| STEM | KTM Integration ICR 0-60° adjust |
| HEADSET | Acros AICR internal 1.5"-1.5" |
| SADDLE | Selle Royal Lookin |
| SEATPOST | KTM TEAM II 30.9/300 |
| PEDALS | MTB-Pedal alloy VPE-527 flat |
| CARRIER | KTM light 42 snap-it 2.0/monkeyload|rack clip |
| LIGHT F | B&M Briq-M 150Lux |
| LIGHT R | B&M Toplight 2C |
| FENDER | front: SKS A65R PET Trek 27,5" - rear: SKS A65R PET Trek 27,5" |
| KICKSTAND | KTM 28" adjustable MY2025 |
| WEIGHT | 28.8 |
| PERMISSIBLE TOTAL WEIGHT | 139 |
Geometry
Geometry
Size
|
40 |
|---|---|
Seattube length
|
430 |
Toptube length
|
585 |
Seat angle
|
71,5° |
Head angle
|
68,0° |
Headtube length
|
165 |
Chainstay length
|
487 |
|---|---|
Wheelbase
|
1131 |
Stack
|
626 |
Reach
|
375 |
Standover height
|
422 |
BB drop
|
62 |
|
Size
|
46 |
|---|---|
|
Seattube length
|
460 |
|
Toptube length
|
590 |
|
Seat angle
|
71,5° |
|
Head angle
|
69,0° |
|
Headtube length
|
165 |
|
Chainstay length
|
487 |
|---|---|
|
Wheelbase
|
1125 |
|
Stack
|
630 |
|
Reach
|
379 |
|
Standover height
|
422 |
|
BB drop
|
62 |
|
Size
|
51 |
|---|---|
|
Seattube length
|
510 |
|
Toptube length
|
600 |
|
Seat angle
|
71,5° |
|
Head angle
|
70,0° |
|
Headtube length
|
174 |
|
Chainstay length
|
487 |
|---|---|
|
Wheelbase
|
1124 |
|
Stack
|
643 |
|
Reach
|
385 |
|
Standover height
|
422 |
|
BB drop
|
62 |
|
Size
|
56 |
|---|---|
|
Seattube length
|
560 |
|
Toptube length
|
615 |
|
Seat angle
|
71,5° |
|
Head angle
|
70,0° |
|
Headtube length
|
190 |
|
Chainstay length
|
487 |
|---|---|
|
Wheelbase
|
1139 |
|
Stack
|
658 |
|
Reach
|
395 |
|
Standover height
|
422 |
|
BB drop
|
62 |
