QUALITY. COMFORT. PERFORMANCE. STYLE. E-Trekking Onroad: One of KTM's most successful segments is entering a new year with an upgrade featuring the BOSCH BDU384Y drive unit. The technically sophisticated recipe for success sounds simple: quality, comfort, performance and style. The TREKKING concept includes a robust aluminum frame, an adjustable stem, and a suspended seat post. It should be emphasized that with the new GRAN models, the successors of the reigning “Stiftung Warentest” winner bike are in this range. The Performance Line CX (BDU384Y) takes riding dynamics and agility to a whole new level. It is powerful, light and quiet (100 Nm max. torque, 750-Watt max. motor power, 400% max. support factor). The Power Tube battery provides 800 Wh. POWER TUBE TOP LOADER (PTTL) is KTM’s innovation for user-friendly battery handling. Removing and reinserting the battery becomes a breeze.
Specification
| FRAME | Macina Trekking Onroad Alloy 6061|PT800 Bosch BDU38/T5940 |
|---|---|
| FORK | Suntour XCM 32 ATB coil 29" LO 80mm |
| MOTOR | Bosch PERFORMANCE CX BDU3840 |
| DISPLAY | Bosch PURION 200 Display & Remote |
| BATTERY | Bosch PowerTUBE 800Wh horizontal |
| CHARGER | Bosch COMPACT Charger 2A |
| R.DERAILL | Shimano CUES U6000-11/10 LG shadow+ |
| SHIFTLEV. | Shimano CUES U6000-10 display |
| CRANKSET | KTM E-COMP ISIS 170mm Q16 |
| SPROCKET | Shimano LG400-10 / 11-48 |
| CHAIN | Shimano LG500 |
| BRAKE | Shimano MT200 / MT200 2-Piston |
| BRAKE-DISC | Shimano RT30 CL 180 / Shimano EM300 CL 160 magnet |
| WHEELSET | Ryde Rival30 32H 622x30C / Ryde Rival30 32H 622x30C |
| TIRE F | Continental Contact Urban 62-622 Reflex |
| TIRE R | Continental Contact Urban 62-622 Reflex |
| GRIPS | GRIP ERGON GP10 |
|---|---|
| BAR | Ergotec Lady Town 630mm |
| STEM | KTM Line adjust. 0-60° ICR |
| HEADSET | Acros AICR internal 1.5"-1.5" |
| SADDLE | Selle Royal Lookin |
| SEATPOST | KTM Line II dropper 30.9 T:100 |
| PEDALS | Trekking-Pedal VP-616 anti-slip |
| CARRIER | KTM light 60 (snap-it 1.0) |
| LIGHT F | Litemove RLX-100 100Lux down |
| LIGHT R | B&M Toplight 2C |
| FENDER | SKS A69R PET Trek 28" |
| CHAINGUARD | KTM type 9 for Bosch BDU38 |
| KICKSTAND | KTM 28" adjustable MY2025 |
| WEIGHT | 28.9 |
| PERMISSIBLE TOTAL WEIGHT | 139 |
| SPOKES | DT Champion 2.0 black / DT Alpine II 2.34 black |
Geometry
Size
|
46 |
|---|---|
Seattube length
|
460 |
Toptube length
|
580 |
Seat angle
|
73,0° |
Head angle
|
69,5° |
Headtube length
|
120 |
Chainstay length
|
474 |
|---|---|
Wheelbase
|
1112 |
Stack
|
591 |
Reach
|
399 |
Standover height
|
791 |
BB drop
|
62 |
|
Size
|
51 |
|---|---|
|
Seattube length
|
510 |
|
Toptube length
|
590 |
|
Seat angle
|
73,0° |
|
Head angle
|
70,5° |
|
Headtube length
|
137 |
|
Chainstay length
|
474 |
|---|---|
|
Wheelbase
|
1112 |
|
Stack
|
611 |
|
Reach
|
403 |
|
Standover height
|
825 |
|
BB drop
|
62 |
|
Size
|
56 |
|---|---|
|
Seattube length
|
560 |
|
Toptube length
|
600 |
|
Seat angle
|
73,0° |
|
Head angle
|
70,5° |
|
Headtube length
|
155 |
|
Chainstay length
|
474 |
|---|---|
|
Wheelbase
|
1123 |
|
Stack
|
628 |
|
Reach
|
408 |
|
Standover height
|
857 |
|
BB drop
|
62 |
|
Size
|
60 |
|---|---|
|
Seattube length
|
600 |
|
Toptube length
|
615 |
|
Seat angle
|
73,0° |
|
Head angle
|
70,5° |
|
Headtube length
|
174 |
|
Chainstay length
|
474 |
|---|---|
|
Wheelbase
|
1138 |
|
Stack
|
646 |
|
Reach
|
418 |
|
Standover height
|
885 |
|
BB drop
|
62 |
