MACINA FOLD 20

1X5 SHIMANO NEXUS

4.099 €

SRP

OLIVE PEARL (BLACK)

RIDE. FOLD. REPEAT. The new MACINA FOLD combines innovative drive technology, clean design, and maximum flexibility – featuring a redesigned frame. With just a few simple steps, the bike folds down completely – ideal for campers, commuters, or anyone who needs to save space on the go. Whether in your motorhome, car trunk, or on the train – your bike is always with you and ready to ride. At its heart lies the new Bosch Performance Line PX motor: powerful, quiet, and efficient – delivering an impressive 90 Nm of torque, up to 700 watts of peak power, and a support factor of up to 400 %. Together with the Bosch PowerTube battery (500 Wh), the low-maintenance belt drive, and the SHIMANO NEXUS hub gear, every ride on the FOLD becomes a comfortable and carefree experience. Compact, strong, and effortless – the MACINA FOLD brings freedom into every corner of your life.

Specification

FRAME	Macina Fold 20" Alloy 6061/T6300
FORK	Macina Fold 20" Alloy
MOTOR	Bosch PERFORMANCE PX BDU3470
DISPLAY	Bosch LED Remote
BATTERY	Bosch PowerTUBE 500Wh horizontal
CHARGER	Bosch STANDARD Charger 4A
SHIFTLEV.	Shimano Nexus 5 Revoshifter
CRANKSET	KTM E-COMP2 ISIS 160mm Q8
SPROCKET	Gates rear-sprocket 30T
CHAIN	Gates drive-belt 118T CDX
BRAKE	Shimano MT200 / MT200 2-Piston
BRAKE-DISC	Shimano RT30 CL 160 / Shimano EM300 CL 160 magnet
WHEELSET	Ryde DISC30 32H 406x30TC / Ryde DISC30 32H 406x30TC
TIRE F	Continental E-Contact Plus 55-406 Reflex
TIRE R	Continental E-Contact Plus 55-406 Reflex

GRIPS	Ergon GP1 short
BAR	KTM Banzei 25.4 560mm
STEM	KTM Banzei 12° folding
HEADSET	KTM Banzei 1.1/8"
SADDLE	Selle Royal Orbis
SEATPOST	KTM Banzai 34/400
PEDALS	Ergotec EP-F folding pedal
CARRIER	KTM Banzei snap-it 2.0/monkeyload\|rack clip
LIGHT F	Litemove SEC-110 110Lux down
LIGHT R	AXA Juno
FENDER	SKS B60 CAB City 20"
KICKSTAND	Atran Velo Zweibein-Mittelständer
WEIGHT	24.5
PERMISSIBLE TOTAL WEIGHT	125
SPOKES	DT Champion 2.0 black / DT Alpine II 2.34 black
